Model NO. | DTCM35FH-190H-M58-AL | Image Circle Diameter (Φmm) | 43.6(35mm Full) | ||||
Magnification(x) | 0.229 | Working Distance(mm) | 330±5 | ||||
NA | 0.0190 | Type | Bi-Telecentric | ||||
Mount | M58 | Object Field of View(Φmm) | 190 | ||||
Best Aperture(f/#) | 6 | MTF30 (lp/mm) | >135 | ||||
Depth of Field(mm) | ±8.4@F11 | Distortion Typical(% max) | <0.1 | ||||
Telecentricity Typical (°max) | <0.1 | Length of I/O(mm) | 880±5 | ||||
Length (mm) | 537.5 | Weight(kg) | 10.6 | ||||
Measured Depth of Field (mm) | 3.4 | Filter Screw Size | M223x1.0 | ||||
Field of View (mm × mm) |
CMV50000 (36.43x27.62) | 159.1x120.6 | |||||
KAI29050/2 (36.17x24.11) 34.8x23.2 | 157.9x105.3 | ||||||
KAI43142 (36.18x24.12) | 158.0x105.3 | ||||||
Compatible Lighting |
Telecentric LED Lighting | DTCL-190H-xW-y | |||||
Beam Diameter 190mm |
35mm Full 0.229X Bi-Telecentric Lenses | DTCM35FH-190H-M58-AL COOLENS®
$9,312.00 USD
Shipping calculated at checkout.
Quantity


Description
-
Description
Model NO. | DTCM35FH-190H-M58-AL | Image Circle Diameter (Φmm) | 43.6(35mm Full) | ||||
Magnification(x) | 0.229 | Working Distance(mm) | 330±5 | ||||
NA | 0.0190 | Type | Bi-Telecentric | ||||
Mount | M58 | Object Field of View(Φmm) | 190 | ||||
Best Aperture(f/#) | 6 | MTF30 (lp/mm) | >135 | ||||
Depth of Field(mm) | ±8.4@F11 | Distortion Typical(% max) | <0.1 | ||||
Telecentricity Typical (°max) | <0.1 | Length of I/O(mm) | 880±5 | ||||
Length (mm) | 537.5 | Weight(kg) | 10.6 | ||||
Measured Depth of Field (mm) | 3.4 | Filter Screw Size | M223x1.0 | ||||
Field of View (mm × mm) |
CMV50000 (36.43x27.62) | 159.1x120.6 | |||||
KAI29050/2 (36.17x24.11) 34.8x23.2 | 157.9x105.3 | ||||||
KAI43142 (36.18x24.12) | 158.0x105.3 | ||||||
Compatible Lighting |
Telecentric LED Lighting | DTCL-190H-xW-y | |||||
Beam Diameter 190mm |
